Scott Scale Gravel 10

The all-new Scale Gravel has arrived on this planet to take on adventures in style. Designed to traverse any type of terrain, the Scale Gravel is lightweight, agile and maneuverable, and offers multiple mounting options.

SCOTT SCALE GRAVEL 10 TECHNICAL SPECIFICATIONS

• Frame

  Scale Carbon HMF
  Adjustable head angle / Syncros Cable Integration System
  Advanced Shock & Standing Damping System
  BB92 / UDH Interface / 12x148mm with 55mm Chainline

• Fork

  Scale Rigid HMF
  Postmount Disc Standard
  Tapered Carbon steerer

• Rear Derailleur

  SRAM S1000 Eagle AXS Transmission 12 Speed
  Wireless Electronic Shift System

• Shift Levers

  SRAM AXS Pod Controller

• Crankset

  SRAM S1000 Eagle Transmission
  DUB / 55mm CL / 34T

• Chain guide

  SCOTT custom

• Bottom Bracket

  SRAM DUB PF 92 MTB Wide / shell 41x92mm

• Chain

  SRAM CN GX Eagle Transmission

• Cassette

  SRAM Eagle XS 1270 Transmission 10-52

• Brakes

  Shimano Deore M6100 Disc

• Brake Disc

  Shimano SM-RT64 CL / 180/F and 160/R

• Handlebars

  Syncros Fraser 2.0 XC Alloy 6061 D.B.
  Flat Bar / 8° / 740mm
  Syncros Performance XC lock-on grips

• Handlebar stem

  Syncros XC 2.0
  Syncros Cable Integration System
  -12° rise / 6061 Alloy / 31.8mm / 1 1/8″

• Seatpost

  Syncros Duncan 2.0 / 10mm offset
  31.6x400mm

• Saddle

  Syncros Belcarra Regular 2.0
  CRMO rails

• Headset

  Syncros – Acros Angle adjust & Cable Routing HS System
  +-0.6° head angle adjustment
  ZS56/28.6 – ZS56/40 MTB

• Front hub

  Formula CL-811 / 15x110mm

• Rear hub

  Formula CL-3248 / 12x148mm

• Spokes

  Stainless Black 15G / 1.8mm

• Rim

  Syncros X-28 / 28H / Tubeless ready

• Front tire

  Maxxis Aspen / 29×2.4″ / 120TPI Foldable Bead
  Tubeless Ready / EXO

• Rear tire

  Maxxis Aspen / 29×2.4″ / 120TPI Foldable Bead
  Tubeless Ready / EXO

• Extra

  SRAM AXS Powerpack

• Accessories

  Spirgrips+ Inner Bar ends

• Weight in kg (approx.)

  10.7 (Tubeless setup)

• Weight in lbs (approx.)

  23.59 (Tubeless setup)

• Total weight

  120kg
  Total weight includes bike, rider, equipment, and potentially additional luggage
