Scott Scale Gravel 20

The SCOTT Scale Gravel has landed on this planet to face adventures with determination. Designed to tackle any type of terrain, the Scale Gravel is lightweight, agile, and easy to handle, offering multiple mounting options.

TECHNICAL SPECIFICATIONS – SCOTT SCALE GRAVEL 20

Frame
Scale Alloy 6061 Custom Butted Tubing, Syncros Cable Integration System
BB92, UDH Interface, 12x148mm with 55mm Chainline

Fork
Scale Rigid HMF
Postmount Disc Standard
Tapered Carbon Steerer

Rear Derailleur
SRAM Eagle 70 Transmission 12 Speed

Shifters
SRAM Eagle 70 Trigger

Crankset
SRAM Eagle 70 Transmission
DUB, 55mm CL, 34T

Chainguide
SCOTT Custom

Bottom Bracket
SRAM DUB PF 92 MTB Wide, shell 41x92mm

Chain
SRAM CN Eagle 70 Transmission

Cassette
SRAM Eagle XS 1270 V2 Transmission 10-52

Brakes
Shimano MT401 Disc Brake

Brake Rotors
Shimano SM-RT10 CL, 180/F and 160/R

Handlebar
Syncros Alloy 6061
T shape Flat, 9°, 740mm
Syncros Performance XC lock-on grips

Stem
Syncros DC 3.0
Syncros Cable Integration System
0° rise, 6061 Alloy, 31.8mm, 1 1/8″

Seatpost
Syncros, 31.6x400mm

Saddle
Syncros Belcarra V2.5 Cut Out

Headset
Syncros – Acros OE Cable Routing HS System
OD 50/62mm, ID 42/56mm

Front Hub
Formula CL-811, 15x110mm

Rear Hub
Formula CL-3248, 12x148mm

Spokes
Stainless Black 15G, 1.8mm

Rims
Syncros X-28, 28H, Tubeless Ready

Front Tire
Maxxis Aspen, 29×2.4″, 120TPI Foldable Bead
Tubeless Ready, EXO

Rear Tire
Maxxis Aspen, 29×2.4″, 120TPI Foldable Bead
Tubeless Ready, EXO

Accessories
Spirgrips+ Inner Bar Ends

Weight in kg (approx.)
11.4 (Tubeless setup without pedals)

Weight in lbs (approx.)
25.13 (Tubeless setup without pedals)

Total Weight Limit
120kg
(The total weight includes the bike, the rider, equipment, and potentially additional luggage.)
